Product Details

Superior’s Vibrating Grizzly® Feeders are more often seen in primary stages,  usually feeding a primary crusher. Designed to handle severe shock loads, the VGI will provide plant continuous feed. The feeder placement is on springs, where vibrating movement pushes the substance to the edge of the discharge, separating the material. Unwanted fines calm down, move into the grizzly gate, growing the volume of content passing into the crusher.

Features

  • Capacities up to 1,400 TPH
  • Unique bottle jack lifting points allow for safer spring maintenance without cranes or loaders
  • Adjustable slope and stroke to increase application flexibility and performance
  • ½” thick abrasion resistant steel protects heavy wear areas and is easily replaceable

Please Contact McCourt Equipment for Specifications on these Additional models:

  • 4220VGF
  • 4820VGF
  • 4824VGF
  • 5420VGF
  • 5424VGF
  • 6024VGF

Technical Specs 3617VGF

  • Dimensions:
    36" X17"
  • Drive Size:
    90 MM
  • HP :
    20
  • Speed:
    650-800
  • Grizzly Single:
    5ft
  • Pan Thickness:
    ¾"
  • Pan Liner:
    ½"
