Product Details

Superior’s Jump Conveyors provide a more accurate feed and help reduce transfer point maintenance. The flexible design allows the conveyors to shift in and out of operation quickly. Their custom-engineered truss design extends their lifetime, giving them a durability that allows for the operation in rugged applications.

Features

  • Radial Receiving Hopper
  • 6-foot discharge Support
  • Belt Scale

Technical Specs 80'

  • Conveyor Length:
    80’-0”
  • Conveyor Ground Length:
    79’-9”
  • Raised Height to Center of Pulley:
    12’-2”
  • Lowered Height to Center Pulley:
    6’-10”
  • Travel Length – 36” Belt Width:
    84’-9”
  • Travel Height – 36’ Belt Width:
    9’-5”
  • Travel Width – 36” Belt Width:
    9’-1”
  • Weight at Axle – 36” Belt Width:
    7,000lbs
  • Weight at Kingpin – 36” Belt Width:
    3,000lbs

Please Contact McCourt Equipment for Specifications on these Additional Jump Conveyor models:

  • 40’
  • 50’
  • 60’
  • 100’
